POWER LIFT HL 2.35 NT BMW

The hydraulic 2-post lift Power Lift HL 2.35 NT BMW with a load capacity of 3500 kg and asymmetrical double telescoping arms is a hydraulic lift specially developed for BMW workshops with a high standard of safety. With the world's fastest lifting and lowering times for hydraulic lifts in their weight class and minimum maintenance requirements (no synchronization ropes, no pulleys, no ratchet) it is the ideal lift for daily continuous use in a garage for vehicles of the middle and upper class. In addition to its impressive technical features, the Power Lift HL 2.35 NT BMW with its elegant design also supports the appearance of the quality-conscious authorised workshop at the end customer.

The Power Lift HL 2.35 NT BMW is equipped as standard with the patented Nussbaum NT and HyperFlow® technologies and has been developed and manufactured by Nussbaum since its ; market launch in 2014 in Kehl-Bodersweier in Baden-Württemberg .

• Lifting time: 23 seconds / Lowering time [AttributeShortCode,attribute=Lowering time,attributeid=62] seconds
• Load capacity: 3500 kg
• Adjustable in width and height (with optional riser pipe extension)
• Compressed air connection and 220 V socket integrated in column
• High quality: Every power unit and every hydraulic cylinder is tested before shipment
• Developed and manufactured in Germany
• Freigegeben von BMW für alle Partnerwerkstätten

The HL NT series is the result of over 40 years of experience in the manufacture and development of high-quality automotive lifts Made in Germany. With specially developed, in-house technologies, we are the only lift manufacturer in the world that can provide you with a precise, variable lowering speed and an always perfect synchronisation without manual maintenance effort anbieten. The ergonomic stepless operating lever Nussbaum-Commander enables sensitive lowering and allows the user to change and correct positions in no time at all, all with maximum safety. The Power Lift HL 2.35 NT BMW is not only safe, but also exceptionally flexible and can be adapted to a wide range of workshop sizes and configurations.Their base frame-free design, adjustable in width and height, enables a wide range of installation combinations and variants:  Mit a minimum height of 4040  mm and a maximum height of 4904 mm thanks to the optional riser pipe extensions the Power Lift HL 2.35 NT BMW lift the underbody of high vehicles such as SUVs and vans to the ideal working height for you.

The pulling hydraulic cylinders protect the hydraulic circuit even during intensive use and require very little energy. The low power consumption, the consistent automatic compensation of the hydraulic circuits by the HyperFlow® system and low maintenance costs, also thanks to the reduced number of moving parts, reduce running costs. The pump unit integrated in a sound-absorbing metal housing is mounted on the control column and easily accessible for maintenance work. A compressed air connection and a 220 V socket are integrated in the control column. The arms and columns made of high-quality steel are welded in Nussbaum's own state-of-the-art welding facilities, shot-peened and subsequently BMW-Weiss powder-coated. Your lift is thus protected against dirt and weather in the long term.

The design and the processing of the Power Lift HL 2.35 NT BMW give it an elegant overall appearance, which also allows your workshop to appear in the best light in direct customer contact.

Scope of delivery

Hebebühne mit asymmetrischen, teleskopierbaren Tragarmen, vier im Tragarm fixierte Drehteller, Energie-Set: E-Set (230 V/ Druckluft) in der Bediensäule integriert, Spezieller Korrossionsschutz (Duplex Beschichtung), CE-Stop, Dokumentenhalter an der Hubsäu

Installation requirements

Fundamentstärke 200mm C20/25 normale Bewehrung, 16 Dübel BM12-20/80/40 (abhängig vom Fundament, siehe Prüfbuch), Elektroanschluss 3 PH, N + PE, 400 V, 50 Hz, Absicherung 16 Amp. träge, Luftanschluss für Energie-Set, Hydrauliköl HLP32 ca. 10l, Entladung
